| Danby Model: DRRM300WC | ||||||
| Factory Model: F766F40P411-CC | ||||||
| Effective Date: 2024-07-08 | ||||||
| Revision: 00 | ||||||
| NO | PART NUMBER | Updated Part # Nov.2024 | PART DESCRIPTION (ENG) | QTY | PARTS SPECIFICATION | Notes |
| 1 | 30307100208 | Storage drawer panel | 1 | White spray，0.5mm | ||
| 2 | 30316200006 | Suction duct baffle | 1 | Black spray cold rolled sheet | ||
| 3 | 30302900238 | Fixed plate for suction duct baffle | 1 | Cold rolled sheet, spray painted black | ||
| 4 | 30204100032 | Door buffer pad | 2 | Black silicone rubber | ||
| 5 | 30200500040 | Range door seal assembly | 1 | Fiberglass+stainless steel buckle(φ13*0.15) | ||
| 6 | 30315000487 | Inner liner panel | 1 | Black spray cold rolled sheet | ||
| 7 | 30400100002 | Racks | 2 | Chromium plating on ordinary steel | ||
| 8 | 30403900027 | Storage room left rail | 1 | Iron chrome plating | ||
| 9 | 30316200099 | Rear cover plate baffle | 1 | Galvanized sheet, 0.5mm | ||
| 10 | 30101200279 | Top electric heating tube 2000W | 1 | |||
| 11 | 2040700302 | Standing oven liner assembly | 1 | Cold rolled sheet black enamel 0.6mm | ||
| 12 | 30101000013 | Round lamp assembly | 2 | |||
| 13 | 30301500004 | Cavity rear bracket | 1 | Galvanized sheet | ||
| 14 | 30102600008 | Cooker junction box | 1 | |||
| 15 | 30313200001 | Stove surface support frame | 1 | Galvanized sheet | ||
| 16 | 30302500005 | Cavity left bracket | 1 | Galvanized sheet | ||
| 17 | 30302500006 | Cavity right bracket | 1 | Galvanized sheet | ||
| 18 | 30313300001 | Fixed block behind the panel | 2 | Galvanized sheet | ||
| 19 | 30302200165 | Shell rear cover plate | 1 | Galvanized sheet, 0.5mm | ||
| 20 | 30313300007 | Power cord fixing buckle | 1 | Galvanized sheet | ||
| 21 | 30302900017 | Power cord fixing plate | 1 | Galvanized sheet | ||
| 22 | 30309600013 | Shell rear cover plate | 1 | Galvanized sheet | ||
| 23 | 30201600011 | Anti slip feet | 4 | silicone rubber | ||
| 24 | 30313200090 | Bottom bracket | 2 | Galvanized sheet | ||
| 25 | 30302700162 | Left-right side panel linker plate | 2 | Galvanized sheet | ||
| 26 | 30307800016 | Storage compartment partition | 1 | Galvanized sheet | ||
| 27 | 30301200002 | Bottom heaters fixing plate | 1 | Galvanized sheet | ||
| 28 | 30101200281 | Bottom electric tube 1500W | 1 | |||
| 29 | 30316200003 | Bottom heater baffle | 2 | Galvanized sheet | ||
| 30 | 30401100007 | Smoke exhaust pipe | 1 | Galvanized sheet | ||
| 31 | 30301800002 | Exhaust flue baseboard | 1 | Galvanized sheet | ||
| 32 | 30100800005 | Heat dissipation thermostat | 1 | |||
| 33 | 30100400074 | Cooling fan assembly | 1 | |||
| 34 | 30100700030 | Overheat protector | 1 | |||
| 35 | 30312600036 | Exhaust duct middle cover | 1 | Galvanized sheet | ||
| 36 | 30312600038 | Exhaust duct top cover | 1 | Galvanized sheet | ||
| 37 | 2040900139 | Range left panel assembly | 1 | Cold rolled sheet white enamel 0.5mm | ||
| 38 | 30406900036 | Non-standard screw | 2 | 430 stainless steel | ||
| 39 | 30302400005 | Left panel support bracket | 1 | Galvanized sheet | ||
| 40 | 30302900308 | Fixed block for switch board | 2 | Galvanized sheet | ||
| 41 | 30302600037 | Hinge fixing bracket | 2 | Galvanized sheet | ||
| 42 | 30302600003 | Hinge fixing plate | 2 | Galvanized sheet | ||
| 43 | 30302400006 | Left panel support bracket | 1 | Galvanized sheet | ||
| 44 | 2040900140 | Range right panel assembly | 1 | Cold rolled sheet white enamel 0.5mm | ||
| 45 | 30302900018 | Inside drawer door fix block | 2 | Galvanized sheet,1.5mm | ||
| 46 | 30307100182 | Storage room lining panel | 1 | Galvanized sheet,0.5mm | ||
| 47 | 30403900028 | Storage room right rail | 1 | Iron chrome plating | ||
| 48 | 30307100181 | Storage room floor | 1 | Galvanized sheet | ||
| 49 | 30302900230 | Pull-out rail fixing plate | 2 | Galvanized sheet,0.7mm | ||
| 50 | 30400700355 | Handle | 1 | Aluminum alloy,610mm, white | ||
| 51 | 30102400209 | 30102400516 | Power cord | 1 | ||
| 52 | 30500201462 | Door panel glass | 1 | Tempered glass,610mm | ||
| 53 | 30303500102 | Door bracket | 1 | Black cold-rolled sheet | ||
| 54 | 30303400193 | Door Frame Left Bracket | 1 | Black cold-rolled sheet | ||
| 55 | 30303400194 | Door Frame Right Bracket | 1 | Black cold-rolled sheet | ||
| 56 | 30200900018 | Lower left glass fixing | 1 | Flame retardant nylon | ||
| 57 | 30200900019 | Lower right glass fixing | 1 | Flame retardant nylon | ||
| 58 | 30400600055 | Hinge | 2 | Galvanized sheet | ||
| 59 | 30500300088 | Middle glass | 1 | Tempered glass | ||
| 60 | 30303700002 | Middle glass limit block | 2 | Black cold-rolled sheet | ||
| 61 | 30201000008 | Middle glass fixing block | 2 | Silicon rubber | ||
| 62 | 30500400155 | Inner glass | 1 | Tempered glass | ||
| 63 | 30201400005 | Handle washer | 2 | Plastic | ||
| 64 | 30303600001 | Handle fixing plate | 1 | Black cold-rolled sheet | ||
| 65 | 30201200006 | Middle glass inlay | 2 | silicon rubber | ||
| 66 | 30201000003 | Middle glass fixing block | 2 | silicon rubber | ||
| 67 | 30402500523 | Knob | 7 | Zinc alloy,white | ||
| 68 | 30201900063 | Waterproof mat | 7 | white plastic | ||
| 69 | 30305900496 | control panel | 1 | White spray 0.7mm | ||
| 70 | 30215300011 | Rubber strip | 1 | Silicone rubber, | ||
| 71 | 30216300013 | Left side panel of the panel | 1 | ppt,white | ||
| 72 | 30216300012 | Right side panel of the panel | 1 | ppt,white | ||
| 73 | 30100100001 | Mechanical timer | 1 | |||
| 74 | 30102200029 | Energy Regulators | 4 | |||
| 75 | 30100500065 | Gear switch | 1 | |||
| 76 | 30100900024 | Temperature control switch | 1 | |||
| 77 | 30102500003 | Oven Indicator light | 1 | plastic，100mm，in control panel | ||
| 78 | 30313300070 | Chassis front support | 2 | Galvanized sheet,2mm | ||
| 79 | 30300500025 | Chassis | 1 | Galvanized sheet | ||
| 80 | 30102500068 | Cooktop Indicator light | 1 | plastic，110V,use for cooktop | ||
| 81 | 30307500002 | Indicator light fixing base | 1 | Galvanized sheet | ||
| 82 | 30307400002 | Radiator plate fixing seat | 12 | Galvanized sheet | ||
| 83 | 30102800068 | Radiation furnace plate 2500W | 1 | |||
| 84 | 30102800067 | Radiation furnace plate 2200W | 1 | |||
| 85 | 30102800069 | Radiation furnace plate 1200W | 2 | |||
| 86 | 2040500285 | Standing oven panel assembly | 1 | Cold rolled sheet white enamel | ||
| 87 | 30502201319 | Cooker glass panel | 1 | Black glass-ceramics | ||
| 88 | 30306200032 | Rear panel | 1 | Cold rolled sheet white enamel | ||
| 89 | 30102101245 | Connecting wires | 1 | UL,electric ceramic stove,wire | ||
| 90 | 30102101366 | Connecting wires | 1 | UL,4 functions,wire harenss | ||
| 91 | 30313200060 | Anti-tilt bracket | 1 | Galvanized sheet | ||
| 92 | 30406900031 | Non-standard screwof bracket | 1 | Galvanized sheet | ||
DRRM300WC part list DRRM300WC part list
